Polyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for Electromagnetic

Product Categories

Enamelled Round Copper Wire

 [72]

Enameled Copper Winding Wire

 [109]

Enamel Insulated Copper Wire

 [21]

Enamel Magnet Wire

 [16]

Enameled Flat Copper Wire

 [3]

Silk Covered Wire

 [12]

Litz Wire

 [10]

High Temperature Magnet Wire

 [17]
Contact Now
Pacific Electric Wire & Cable (Shenzhen) Co., Ltd.
Visit Website
City:shenzhen
Country/Region:china
Contact Person:MissGong
View Contact Details
Contact Now
China Polyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for Electromagnetic wholesale
  • China Polyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for Electromagnetic wholesale
  • China Polyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for Electromagnetic wholesale

Polyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for Electromagnetic
Ask Latest Price
Video Channel
Brand Name :PEWSC
Model Number :PEW AWG 40-8
Certification :UL,ROHS
Place of Origin :China
MOQ :The MOQ Varies According to the Size of the Specification
Price :Copper price plus processing fee plus freight
Payment Terms :T/T 100% Payment before Shipment
Supply Ability :Delivery 10-15 Days after Next Order
Delivery Time :3-5 Work Days
Packaging Details :Box
Model :PEW AWG 40-8
Material :Copper
Rated Voltage :2800V The Voltage Resistance Varies According to the Thickness of the Film and the Size of the Specification
Temperature Grad :155℃
Applications :For Electromagnetic
Color Options :Could be Customized
Sample :Free
Warranty :3 years
Shape :Round
Package :Carton
more
Contact Now

Add to Cart
Find Similar Videos
Overcoat Polyamide Enamel Insulated Copper Wire heat resistant AWG 46-18 00:28
Overcoat Polyamide Enamel Insulated Copper Wire heat resistant AWG 46-18
Solid or Stranded Enamel Insulated Copper Wire With Certifications 00:45
Solid or Stranded Enamel Insulated Copper Wire With Certifications
0.10mm - 2.20mm Enameled Insulated Wire Overcoat Polyamide Copper Wire Thermal Class 155 04:57
0.10mm - 2.20mm Enameled Insulated Wire Overcoat Polyamide Copper Wire Thermal Class 155
Thermal Class 155 Polyester Enamelled Cable PEW Grade Two Non Weldable ROHS Approved 04:53
Thermal Class 155 Polyester Enamelled Cable PEW Grade Two Non Weldable ROHS Approved
Modified Polyurethane Litz Wire / Enamelled Copper Wire No Injuries And Adhesion 02:34
Modified Polyurethane Litz Wire / Enamelled Copper Wire No Injuries And Adhesion
Copper Round Enameled Winding Wire Overcoat Polyamide Imide HAI 0.20mm-2.00mm Single 00:20
Copper Round Enameled Winding Wire Overcoat Polyamide Imide HAI 0.20mm-2.00mm Single
View Product Description

0.08mm-3.20mm polyester enamelled wire PEW Grade three Non weldable 155 Thermal Class 155

PEW Grade three is a high quality enameled wire designed for industrial and professional applications. This product utilizes a three-layer coating technology that provides excellent insulation and heat resistance, making it ideal for use in a variety of harsh environments.

PEW Grade three has a uniform, smooth coating that prevents current leakage and electromagnetic interference. At the same time, its high strength and flexibility enable it to withstand large current loads and mechanical stresses, ensuring stable equipment operation.

In addition, PEW Grade three meets the requirements of environmental protection and is manufactured with non-toxic and harmless materials, which is non-polluting to the environment. The product has a long service life, which can reduce the maintenance cost and update frequency of the equipment, saving a lot of money and time for users.

All in all, PEW Grade three is a superior performance and reliable quality solenoid material that is ideal for industrial and professional applications.

Polyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for ElectromagneticPolyester Enamel Covered Wire AWG 40-8 Non Weldable Thermal Class 155 PEW for Electromagnetic

GB ---Grade3 Unit﹕mm
Diameter of
Conduct		 Conductor
Tolerance		 Conductor Control
Benchmarks		 OD Control
Benchmarks		 Specification Boundaries Conductor
Resistance 20℃
(Ω/KM)		 Min Elongation
(%)		 Max.
Springiness
(°)		 Insulation breakdown voltage
(v)
Lower
Limit		 Upper
Limit		 Lower
Limit		 Upper
Limit		 Min. Increase
in Diameter		 Max. Finished
overall Diameter
0.071 ±0.003 0.070 0.072 0.09 0.095 0.018 0.097 4747 13 -- 1100
0.080 ±0.003 0.079 0.081 0.101 0.107 0.020 0.108 3703 14 100 1200
0.090 ±0.003 0.089 0.091 0.113 0.119 0.022 0.120 2900 15 94 1300
0.100 ±0.003 0.099 0.101 0.124 0.131 0.023 0.132 2333 16 90 1400
0.112 ±0.003 0.111 0.114 0.139 0.146 0.026 0.147 1848 17 88 3900
0.125 ±0.003 0.124 0.127 0.154 0.161 0.028 0.163 1475 17 84 4100
0.140 ±0.003 0.139 0.142 0.171 0.178 0.030 0.181 1170 18 79 4200
0.160 ±0.003 0.159 0.162 0.194 0.201 0.033 0.205 890.6 19 78 4400
0.180 ±0.003 0.179 0.182 0.218 0.225 0.036 0.229 700.7 20 75 4700
0.200 ±0.003 0.199 0.202 0.241 0.249 0.039 0.252 565.7 21 72 5100
0.224 ±0.003 0.223 0.226 0.269 0.277 0.043 0.280 449.5 21 68 5200
0.250 ±0.004 0.249 0.253 0.301 0.309 0.048 0.312 362.8 22 65 5500
0.280 ±0.004 0.279 0.283 0.333 0.341 0.050 0.345 288.2 22 61 5800
0.315 ±0.004 0.314 0.317 0.371 0.38 0.053 0.384 227.0 23 62 6100
0.355 ±0.004 0.354 0.357 0.415 0.423 0.057 0.428 178.2 23 59 6400
0.400 ±0.005 0.398 0.403 0.464 0.474 0.060 0.478 140.7 24 55 6600
0.450 ±0.005 0.448 0.453 0.518 0.528 0.064 0.533 110.9 25 53 6800
0.500 ±0.005 0.498 0.503 0.571 0.581 0.067 0.587 89.59 25 51 7000
0.560 ±0.006 0.557 0.563 0.635 0.645 0.071 0.653 71.53 26 48 7100
0.630 ±0.006 0.627 0.633 0.709 0.721 0.075 0.728 56.38 27 53 7100
0.710 ±0.007 0.707 0.714 0.795 0.807 0.080 0.814 44.42 28 50 7200
0.800 ±0.008 0.797 0.804 0.89 0.902 0.085 0.911 35.00 28 46 7400
0.900 ±0.009 0.897 0.904 0.995 1.007 0.090 1.018 27.65 29 51 7600
1.000 ±0.010 0.997 1.004 1.1 1.114 0.095 1.124 22.40 30 47 7600
1.120 ±0.011 1.116 1.124 1.223 1.237 0.098 1.248 17.85 30 34 7600
1.250 ±0.013 1.246 1.254 1.355 1.369 0.100 1.381 14.35 31 39 7600
1.400 ±0.014 1.396 1.406 1.509 1.523 0.103 1.535 11.43 32 36 7600
1.600 ±0.016 1.596 1.606 1.714 1.73 0.107 1.740 8.75 32 32 7600
1.800 ±0.018 1.796 1.806 1.917 1.933 0.110 1.944 6.91 32 7600
2.000 ±0.020 1.994 2.006 2.12 2.136 0.113 2.148 5.60 33 7600
2.240 ±0.022 2.234 2.246 2.363 2.381 0.116 2.392 4.46 33 7600
2.500 ±0.025 2.494 2.506 2.626 2.644 0.119 2.656 3.58 33 7600
2.800 ±0.028 2.794 2.808 2.932 2.95 0.123 2.961 2.86 34 3800
3.150 ±0.032 3.144 3.158 3.286 3.306 0.127 3.316 2.26 34 3800
